SMA4F8.5A
RoHS
RoHS compliant
RoHS compliantPackage DO-221AC, SMA Flat Leads
Category Circuit Protection / TVS - Diodes
Description
400 W TVS IN SMA FLAT
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.2904
≥100 USD $0.17424
≥500 USD $0.161322
≥1000 USD $0.109692
≥3000 USD $0.100989
Inventory: 1633
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case DO-221AC, SMA Flat Leads
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series SMA4F, TRANSIL?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Zener
Applications General Purpose
Peak Reflow Temperature (Cel) 260
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number SMA4F
Power Line Protection No
Voltage - Breakdown (Min) 9.4V
Power - Peak Pulse 400W
Current - Peak Pulse (10/1000μs) 27.7A
Voltage - Clamping (Max) @ Ipp 19.5V
Voltage - Reverse Standoff (Typ) 8.5V
Unidirectional Channels 1
Compliance
RoHS Status RoHS Compliant
