SM6T7V5CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 6.4V 14.5V SMB
PDF
/
Buying Options
Total Price: USD $0.65
Unit Price: USD $0.6512
≥1 USD $0.6512
≥10 USD $0.56232
≥100 USD $0.389576
≥500 USD $0.325494
≥1000 USD $0.277024
Inventory: 1407
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.45mm
Technical
Number of Registers 93296
Max Breakdown Voltage 7.9V
Bidirectional Channels 1
Breakdown Voltage 7.13V
Test Current 10mA
Direction Bidirectional
Peak Pulse Power 600W
Reverse Standoff Voltage 6.4V
Peak Pulse Current 276A
Clamping Voltage 14.5V
Voltage - Clamping (Max) @ Ipp 14.5V
Max Reverse Leakage Current 20μA
Current - Peak Pulse (10/1000μs) 276A 8/20μs
Power Line Protection No
RAM Size 387kB
Element Configuration Single
Number of Elements 1
Operating Supply Voltage 1.2V
Pin Count 2
Base Part Number SM6T
Time@Peak Reflow Temperature-Max (s) 60
Peak Reflow Temperature (Cel) 245
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 600W
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SM6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
