SM6T6V8AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5.8VWM 13.4VC SMB
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
≥10 USD $0.5104
≥100 USD $0.353144
≥500 USD $0.295082
≥1000 USD $0.251143
Inventory: 1600
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SM6TY, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 245
Time@Peak Reflow Temperature-Max (s) 60
Base Part Number SM6T
Pin Count 2
Number of Elements 1
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 298A 8/20μs
Max Reverse Leakage Current 20μA
Voltage - Clamping (Max) @ Ipp 13.4V
Clamping Voltage 13.4V
Peak Pulse Current 298A
Reverse Standoff Voltage 5.8V
Peak Pulse Power 600W
Direction Unidirectional
Test Current 10mA
Unidirectional Channels 1
Breakdown Voltage 6.45V
Max Breakdown Voltage 7.1V
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
