SM6T68CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 58.1V 121V SMB
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.34672
≥100 USD $0.207856
≥500 USD $0.192421
≥1000 USD $0.130847
Inventory: 24169
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.65mm
Technical
Max Junction Temperature (Tj) 150°C
Max Breakdown Voltage 71.4V
Non-rep Peak Rev Power Dis-Max 4000W
Reverse Breakdown Voltage 64.6V
Breakdown Voltage 71.4V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 6.5A
Reverse Standoff Voltage 58.1V
Peak Pulse Current 6.5A
Voltage - Reverse Standoff (Typ) 58.1V
Clamping Voltage 92V
Voltage - Clamping (Max) @ Ipp 121V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 33A 8/20μs
Power Line Protection No
Power Dissipation 600W
Element Configuration Single
Leakage Current 200nA
Number of Channels 1
Number of Elements 1
Operating Supply Voltage 68V
Pin Count 2
Base Part Number SM6T
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 600W
Voltage - Rated DC 68V
Power Rating 600W
Subcategory Transient Suppressors
Capacitance 625pF
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM6T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
