SM6T68AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 58.1VWM 121VC SMB
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.78408
≥100 USD $0.609752
≥500 USD $0.516859
≥1000 USD $0.421036
Inventory: 2492
Minimum: 1
-
+
Technical Details
Technical
Terminal Finish Matte Tin (Sn) - annealed
Applications Automotive
Subcategory Transient Suppressors
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 245
Time@Peak Reflow Temperature-Max (s) 60
Base Part Number SM6T
Pin Count 2
Number of Elements 1
Leakage Current 200nA
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 33A 8/20μs
Max Reverse Leakage Current 200nA
Voltage - Clamping (Max) @ Ipp 121V
Clamping Voltage 121V
Peak Pulse Current 33A
Reverse Standoff Voltage 58.1V
Peak Pulse Power 600W
Direction Unidirectional
Test Current 1mA
Breakdown Voltage 64.6V
Reverse Breakdown Voltage 64.6V
Max Breakdown Voltage 71.4V
Number of Unidirectional Channels 1
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SM6TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
