SM6T56CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 47.6V 100V SMB
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.396
≥100 USD $0.273856
≥500 USD $0.228818
≥1000 USD $0.21428
Inventory: 1213
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SM6TY, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 245
Time@Peak Reflow Temperature-Max (s) 60
Base Part Number SM6T
Pin Count 2
Number of Elements 1
Working Voltage 64.1V
Number of Channels 1
Leakage Current 200nA
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Max Reverse Leakage Current 1μA
Voltage - Clamping (Max) @ Ipp 100V
Clamping Voltage 100V
Peak Pulse Current 40A
Reverse Standoff Voltage 47.6V
Peak Pulse Power 600W
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 53.2V
Reverse Breakdown Voltage 53.2V
Max Breakdown Voltage 58.8V
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
