SM6T56CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 47.6V 100V SMB
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
≥10 USD $0.44528
≥100 USD $0.309672
≥500 USD $0.241771
≥1000 USD $0.196513
Inventory: 2726
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 4000W
Reverse Breakdown Voltage 53.2V
Breakdown Voltage 53.2V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 1mA
Reverse Standoff Voltage 47.6V
Peak Pulse Current 40A
Clamping Voltage 100V
Voltage - Clamping (Max) @ Ipp 100V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Power Line Protection No
Element Configuration Single
Power Dissipation-Max 5W
Leakage Current 200nA
Number of Elements 1
Operating Supply Voltage 47.6V
Pin Count 2
Base Part Number SM6T
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM6T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
