SM6T39AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 33.3VWM 69.7VC SMB
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.71456
≥100 USD $0.555456
≥500 USD $0.470818
≥1000 USD $0.383539
Inventory: 1110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SM6TY, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Additional Feature UL RECOGNIZED
Subcategory Transient Suppressors
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 245
Time@Peak Reflow Temperature-Max (s) 60
Base Part Number SM6T
Pin Count 2
Number of Elements 1
Leakage Current 200nA
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 57A 8/20μs
Max Reverse Leakage Current 200nA
Voltage - Clamping (Max) @ Ipp 69.7V
Clamping Voltage 69.7V
Peak Pulse Current 57A
Reverse Standoff Voltage 33.3V
Peak Pulse Power 600W
Direction Unidirectional
Test Current 1mA
Breakdown Voltage 37.1V
Reverse Breakdown Voltage 37.1V
Max Breakdown Voltage 41V
Number of Unidirectional Channels 1
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
