SM6T27CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 23.1V 48.3V SMB
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.13269
≥1 USD $0.13269
≥10 USD $0.12518
≥100 USD $0.11809
≥500 USD $0.11141
≥1000 USD $0.1051
≥3000 USD $0.09915
Inventory: 11359
Minimum: 1
-
+
Technical Details
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.45mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Technical
Max Breakdown Voltage 28.4V
Non-rep Peak Rev Power Dis-Max 4000W
Reverse Breakdown Voltage 25.7V
Breakdown Voltage 25.7V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 600W
Max Surge Current 1mA
Reverse Standoff Voltage 23.1V
Peak Pulse Current 83A
Clamping Voltage 48.3V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 83A 8/20μs
Power Line Protection No
Power Dissipation 600W
Element Configuration Single
Leakage Current 200nA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 27V
Pin Count 2
Base Part Number SM6T
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 27V
Power Rating 600W
Subcategory Transient Suppressors
Capacitance 1.15nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM6T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
