SM6HT43A image
Favorite
SM6HT43A image
Favorite
RoHS
RoHS RoHS compliant
Package DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 36.8V 59.3V SMB
PDF
/
Inventory: 1508
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 3.95mm
Length 4.6mm
Height 2.45mm

Technical

Number of Unidirectional Channels 1
Reverse Breakdown Voltage 40.9V
Breakdown Voltage 40.9V
Test Current 1mA
Peak Pulse Power 600W
Max Surge Current 10.1A
Reverse Standoff Voltage 36.8V
Peak Pulse Current 10.1A
Clamping Voltage 59.3V
Voltage - Clamping (Max) @ Ipp 59.3V
Power Line Protection No
Leakage Current 2μA
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Operating Supply Voltage 36.8V
Pin Count 2
Base Part Number SM6HT
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 600W
Voltage - Rated DC 43V
Power Rating 600W
Subcategory Transient Suppressors
Additional Feature HIGH RELIABILITY
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series SM6HT, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -65°C~175°C TJ

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
