SM6HT27A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 23.1VWM 37.5VC SMB
PDF
/
Inventory: 1126
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -65°C~175°C TJ
Packaging Tape & Reel (TR)
Series SM6HT, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature HIGH RELIABILITY
Subcategory Transient Suppressors
Power Rating 600W
Voltage - Rated DC 27V
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Base Part Number SM6HT
Pin Count 2
Operating Supply Voltage 23.1V
Number of Elements 1
Polarity Unidirectional
Configuration SINGLE
Leakage Current 2μA
Power Line Protection No
Current - Peak Pulse (10/1000μs) 16A
Voltage - Clamping (Max) @ Ipp 37.5V
Clamping Voltage 37.5V
Peak Pulse Current 16A
Reverse Standoff Voltage 23.1V
Max Surge Current 16A
Peak Pulse Power 600W
Test Current 1mA
Unidirectional Channels 1
Breakdown Voltage 25.7V
Reverse Breakdown Voltage 25.7V
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
