SM5908
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5V 8.5V SMC
PDF
/
Buying Options
Total Price: USD $1.37
Unit Price: USD $1.3728
≥1 USD $1.3728
≥10 USD $1.13872
≥100 USD $0.906576
≥500 USD $0.767131
≥1000 USD $0.650901
Inventory: 6517
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~175°C TJ
Packaging Tape & Reel (TR)
Series TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 9.5nF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 5V
Max Power Dissipation 5W
Technology AVALANCHE
Terminal Position AXIAL
Terminal Form WIRE
Peak Reflow Temperature (Cel) 260
Base Part Number SM5908
Pin Count 2
Operating Supply Voltage 5V
Number of Elements 1
Polarity Unidirectional
Leakage Current 300μA
Element Configuration Single
Power Dissipation 5W
Case Connection ISOLATED
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 120A 8/20μs
Max Reverse Leakage Current 300μA
Clamping Voltage 8.5V
Peak Pulse Current 120A
Reverse Standoff Voltage 5V
Max Surge Current 60A
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 6V
Rep Pk Reverse Voltage-Max 5V
Reverse Breakdown Voltage 6V
Max Breakdown Voltage 6V
Number of Unidirectional Channels 1
Dimensions
Height 2.45mm
Length 7.15mm
Width 6.25mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
