SM4T56CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 48VWM 100VC SMA
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.46992
≥100 USD $0.365112
≥500 USD $0.309514
≥1000 USD $0.306134
Inventory: 14963
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 2.9mm
Length 4.6mm
Height 2.45mm
Technical
Max Breakdown Voltage 58.9V
Reverse Breakdown Voltage 53.3V
Breakdown Voltage 53.3V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 400W
Reverse Standoff Voltage 48V
Peak Pulse Current 23A
Clamping Voltage 100V
Voltage - Clamping (Max) @ Ipp 100V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 23A 8/20μs
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Number of Elements 1
Pin Count 2
Base Part Number SM4T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 400W
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SM4TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
