SM4T18AY image
Favorite
SM4T18AY image
Favorite
RoHS
RoHS RoHS compliant
Package DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 15VWM 32.5VC SMA
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7832
≥1 USD $0.7832
≥10 USD $0.63888
≥100 USD $0.496848
≥500 USD $0.42115
≥1000 USD $0.343068
≥3000 USD $0.32296
Inventory: 1294
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON

Technical

Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SM4TY, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Max Power Dissipation 400W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Base Part Number SM4T
Pin Count 2
Number of Elements 1
Element Configuration Single
Power Line Protection No
Current - Peak Pulse (10/1000μs) 71A 8/20μs
Max Reverse Leakage Current 200nA
Voltage - Clamping (Max) @ Ipp 32.5V
Clamping Voltage 32.5V
Peak Pulse Current 71A
Reverse Standoff Voltage 15V
Peak Pulse Power 400W
Direction Unidirectional
Test Current 1mA
Unidirectional Channels 1
Breakdown Voltage 16.7V
Max Breakdown Voltage 18.5V

Dimensions

Height 2.45mm
Length 4.6mm
Width 2.9mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
