SM4T15CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Circuit Protection / TVS - Diodes
Description
TVS Diodes - Transient Voltage Suppressors 400 W 2.3kW Transil 5V to 70V Bi
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.45408
≥100 USD $0.3146
≥500 USD $0.262838
≥1000 USD $0.223696
≥3000 USD $0.199232
Inventory: 7600
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 2.9mm
Length 4.6mm
Height 2.45mm
Technical
Max Breakdown Voltage 16V
Bidirectional Channels 1
Breakdown Voltage 14.4V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 400W
Reverse Standoff Voltage 13V
Peak Pulse Current 85A
Clamping Voltage 27.2V
Voltage - Clamping (Max) @ Ipp 27.2V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 85A 8/20μs
Power Line Protection No
Element Configuration Single
Working Voltage 5.8V
Number of Elements 1
Pin Count 2
Base Part Number SM4T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 400W
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SM4TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AC, SMA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 17 Weeks
