SM30T33CAY

STMicroelectronics
RoHS
RoHS RoHS compliant
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description Transient Voltage Suppressor, TVS, AEC-Q101 Transil SM30TY Series, Bidirectional, 28 V, DO-214AB, 2
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2408
≥1 USD $1.2408
≥10 USD $1.01728
≥100 USD $0.791032
≥500 USD $0.670472
≥1000 USD $0.546181
Inventory: 1411
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 6.25mm
Length 7.15mm
Height 2.45mm

Technical

Max Breakdown Voltage 34.3V
Non-rep Peak Rev Power Dis-Max 3000W
Bidirectional Channels 1
Breakdown Voltage 31.1V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 3kW
Reverse Standoff Voltage 28V
Peak Pulse Current 66.1A
Clamping Voltage 45.4V
Voltage - Clamping (Max) @ Ipp 45.4V
Max Reverse Leakage Current 200nA
Power - Peak Pulse 3000W 3kW
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Working Voltage 28V
Number of Elements 1
Pin Count 2
Base Part Number SM30T
Depth 6.25mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3kW
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM30TY, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
