SM30T26AY image
Favorite
SM30T26AY image
Favorite
RoHS
RoHS RoHS compliant
Package DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 22VWM 35.5VC SMC
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188
≥1 USD $1.188
≥10 USD $0.97328
≥100 USD $0.757064
≥500 USD $0.641678
≥1000 USD $0.52272
Inventory: 1152
Minimum: 1
-
+

Technical Details

Technical

Direction Unidirectional
Breakdown Voltage 24.4V
Non-rep Peak Rev Power Dis-Max 3000W
Max Breakdown Voltage 27V
Number of Unidirectional Channels 1
Peak Pulse Power 3kW
Reverse Standoff Voltage 22V
Peak Pulse Current 84.5A
Clamping Voltage 35.5V
Voltage - Clamping (Max) @ Ipp 35.5V
Current - Peak Pulse (10/1000μs) 84.5A
Power - Peak Pulse 3000W 3kW
Power Line Protection No
Configuration SINGLE
Working Voltage 22V
Number of Elements 1
Pin Count 2
Base Part Number SM30T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 3kW
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM30TY, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
