SM30T12CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
STMICROELECTRONICS SM30T12CAY TVS Diode, SM30T Series
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 2464
Minimum: 1
-
+
Technical Details
Technical
Number of Terminations 2
ECCN Code EAR99
Type Zener
Applications Automotive
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Base Part Number SM30T
Number of Elements 1
Element Configuration Single
Power Line Protection No
Power - Peak Pulse 3000W 3kW
Max Reverse Leakage Current 200nA
Voltage - Clamping (Max) @ Ipp 17V
Clamping Voltage 17V
Peak Pulse Current 176A
Reverse Standoff Voltage 10V
Peak Pulse Power 3kW
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 11.4V
Bidirectional Channels 1
Non-rep Peak Rev Power Dis-Max 3000W
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM30TY, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
