SM2T6V8A
RoHS
RoHS compliant
RoHS compliantPackage DO-216AA
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5V 9.2V DO216AA
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.39864
≥100 USD $0.277288
≥500 USD $0.216515
≥1000 USD $0.175982
≥3000 USD $0.157318
Inventory: 38954
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 2.05mm
Length 2.05mm
Height 1.15mm
Technical
ESD Protection Yes
Max Breakdown Voltage 6.4V
Reverse Breakdown Voltage 6.4V
Breakdown Voltage 6.4V
Test Current 10mA
Direction Unidirectional
Peak Pulse Power 200W
Max Surge Current 19.6A
Reverse Standoff Voltage 5V
Peak Pulse Current 19.6A
Clamping Voltage 9.2V
Max Reverse Leakage Current 50μA
Power Line Protection No
Case Connection CATHODE
Power Dissipation 200W
Element Configuration Single
Leakage Current 50μA
Polarity Unidirectional
Working Voltage 5V
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 2
Base Part Number SM2T
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Technology AVALANCHE
Max Power Dissipation 2.5W
Power Rating 200W
Subcategory Transient Suppressors
Capacitance 1.6nF
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM2T, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-216AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
