SM15T47CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 40.2VWM 84VC SMC
PDF
/
Inventory: 7040
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Max Breakdown Voltage 49.4V
Bidirectional Channels 1
Breakdown Voltage 44.7V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 1.5kW
Max Surge Current 23.2A
Reverse Standoff Voltage 40.2V
Peak Pulse Current 119A
Clamping Voltage 84V
Voltage - Clamping (Max) @ Ipp 84V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 119A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Working Voltage 40.2V
Number of Elements 1
Operating Supply Voltage 40.2V
Pin Count 2
Base Part Number SM15T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
