SM15T36CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 30.8V 64.3V SMC
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 1500
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.65mm
Technical
Max Junction Temperature (Tj) 150°C
ESD Protection Yes
Max Breakdown Voltage 37.8V
Reverse Breakdown Voltage 34.2V
Rep Pk Reverse Voltage-Max 30V
Breakdown Voltage 34.2V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 30.8V
Peak Pulse Current 156A
Clamping Voltage 64.3V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 156A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Power Dissipation 1.5kW
Element Configuration Single
Leakage Current 200nA
Number of Channels 1
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 36V
Pin Count 2
Base Part Number SM15T
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 36V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 2.5nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM15T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
