SM15T30CA
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 25.6V 53.5V SMC
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.64592
≥100 USD $0.50248
≥500 USD $0.425885
≥1000 USD $0.346931
Inventory: 2174
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Max Breakdown Voltage 31.5V
Reverse Breakdown Voltage 28.5V
Breakdown Voltage 28.5V
Test Current 1mA
Peak Pulse Power 1.5kW
Max Surge Current 1mA
Reverse Standoff Voltage 25.6V
Peak Pulse Current 187A
Clamping Voltage 53.5V
Max Reverse Leakage Current 200nA
Current - Peak Pulse (10/1000μs) 187A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Power Dissipation 1.5kW
Element Configuration Single
Leakage Current 200nA
Polarity Bidirectional
Number of Elements 1
Operating Supply Voltage 30V
Pin Count 2
Base Part Number SM15T
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Voltage - Rated DC 30V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 2.9nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM15T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
