SM15T27CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 23.1V 48.3V SMC
PDF
/
Buying Options
Total Price: USD $0.93
Unit Price: USD $0.9328
≥1 USD $0.9328
≥10 USD $0.76384
≥100 USD $0.593912
≥500 USD $0.503413
≥1000 USD $0.41008
Inventory: 1265
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Max Breakdown Voltage 28.4V
Reverse Breakdown Voltage 25.7V
Breakdown Voltage 25.7V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 1.5kW
Max Surge Current 40A
Reverse Standoff Voltage 23.1V
Peak Pulse Current 207A
Clamping Voltage 48.3V
Voltage - Clamping (Max) @ Ipp 48.3V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 207A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Working Voltage 23.1V
Number of Elements 1
Operating Supply Voltage 23.1V
Pin Count 2
Base Part Number SM15T
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
