SM15T24AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20.5VWM 42.8VC SMC
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.72248
≥100 USD $0.562144
≥500 USD $0.47652
≥1000 USD $0.388177
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications Automotive
Subcategory Transient Suppressors
Max Power Dissipation 1.5kW
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Base Part Number SM15T
Pin Count 2
Number of Elements 1
Working Voltage 20.5V
Configuration SINGLE
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 234A 8/20μs
Voltage - Clamping (Max) @ Ipp 42.8V
Clamping Voltage 42.8V
Peak Pulse Current 234A
Reverse Standoff Voltage 20.5V
Peak Pulse Power 1.5kW
Direction Unidirectional
Unidirectional Channels 1
Breakdown Voltage 22.8V
Max Breakdown Voltage 25.2V
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
