SM15T220A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 188VWM 388VC SMC
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.65912
≥100 USD $0.512512
≥500 USD $0.434438
≥1000 USD $0.353892
Inventory: 1188
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series SM15T, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 625pF
Subcategory Transient Suppressors
Power Rating 1.5kW
Voltage - Rated DC 220V
Max Power Dissipation 5W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number SM15T
Pin Count 2
Operating Supply Voltage 188V
Number of Elements 1
Polarity Unidirectional
Leakage Current 200nA
Element Configuration Single
Power Dissipation 1.5kW
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 26A 8/20μs
Max Reverse Leakage Current 1μA
Clamping Voltage 388V
Peak Pulse Current 26A
Reverse Standoff Voltage 188V
Max Surge Current 4.6A
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 209V
Reverse Breakdown Voltage 209V
Max Breakdown Voltage 231V
Number of Unidirectional Channels 1
Dimensions
Height 2.45mm
Length 7.15mm
Width 6.25mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
