SM15T18CAY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 15.3VWM 32.5VC SMC
PDF
/
Inventory: 6318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Max Breakdown Voltage 18.9V
Bidirectional Channels 1
Breakdown Voltage 17.1V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 1.5kW
Max Surge Current 59.5A
Reverse Standoff Voltage 15.3V
Peak Pulse Current 308A
Clamping Voltage 32.5V
Voltage - Clamping (Max) @ Ipp 32.5V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 308A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Working Voltage 15.3V
Number of Elements 1
Operating Supply Voltage 15.3V
Pin Count 2
Base Part Number SM15T
Depth 6.25mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
