SM15T18AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 15.3V 32.5V SMC
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.72248
≥100 USD $0.562144
≥500 USD $0.47652
≥1000 USD $0.388177
Inventory: 1475
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.45mm
Technical
Number of Unidirectional Channels 1
Max Breakdown Voltage 18.9V
Breakdown Voltage 17.1V
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 1.5kW
Max Surge Current 59.5A
Reverse Standoff Voltage 15.3V
Peak Pulse Current 308A
Clamping Voltage 32.5V
Voltage - Clamping (Max) @ Ipp 32.5V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 308A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Element Configuration Single
Leakage Current 200nA
Working Voltage 15.3V
Number of Elements 1
Operating Supply Voltage 15.3V
Pin Count 2
Base Part Number SM15T
Depth 6.25mm
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Subcategory Transient Suppressors
Applications Automotive
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
