SM15T15A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12.8V 27.2V SMC
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.62744
≥100 USD $0.487696
≥500 USD $0.413389
≥1000 USD $0.33675
Inventory: 4857
Minimum: 1
-
+
Technical Details
Technical
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number SM15T
Pin Count 2
Max Output Current 368A
Operating Supply Voltage 15V
Number of Elements 1
Polarity Unidirectional
Leakage Current 200nA
Element Configuration Single
Power Dissipation 1.5kW
Power Line Protection No
Power - Peak Pulse 1500W 1.5kW
Current - Peak Pulse (10/1000μs) 368A 8/20μs
Max Reverse Leakage Current 200nA
Clamping Voltage 27.2V
Peak Pulse Current 368A
Reverse Standoff Voltage 12.8V
Max Surge Current 1mA
Peak Pulse Power 1.5kW
Test Current 1mA
Breakdown Voltage 14.3V
Peak Reverse Current 1mA
Reverse Breakdown Voltage 14.3V
Max Breakdown Voltage 15.8V
ESD Protection Yes
Number of Unidirectional Channels 1
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Voltage - Rated DC 15V
Power Rating 1.5kW
Subcategory Transient Suppressors
Capacitance 5nF
Additional Feature UL RECOGNIZED
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series SM15T, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Dimensions
Height 2.45mm
Length 7.15mm
Width 6.25mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
