SM15T10AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 8.55VWM 18.6VC SMC
PDF
/
Buying Options
Total Price: USD $0.88
Unit Price: USD $0.88
≥1 USD $0.88
≥10 USD $0.72248
≥100 USD $0.562144
≥500 USD $0.47652
≥1000 USD $0.388177
Inventory: 1174
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Breakdown Voltage 10.5V
Breakdown Voltage 9.5V
Unidirectional Channels 1
Direction Unidirectional
Peak Pulse Power 1.5kW
Reverse Standoff Voltage 8.55V
Peak Pulse Current 538A
Clamping Voltage 18.6V
Voltage - Clamping (Max) @ Ipp 18.6V
Current - Peak Pulse (10/1000μs) 538A 8/20μs
Power - Peak Pulse 1500W 1.5kW
Power Line Protection No
Configuration SINGLE
Working Voltage 8.55V
Number of Elements 1
Base Part Number SM15T
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 1.5kW
Applications Automotive
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101, SM15TY, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
