SA16B3RL image
Favorite
SA16B3RL image
Favorite
RoHS
RoHS RoHS compliant
Package 20-SOIC (0.295, 7.50mm Width)
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 7.5VWM 20-SO
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 1060
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 16

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series SA16
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Zener
Applications General Purpose
Subcategory Other Diodes
Voltage - Rated DC 7.5V
Current Rating 50mA
Base Part Number SM6T
Polarity Bidirectional
Power Dissipation 850mW
Power Line Protection No
Max Reverse Leakage Current 5μA
Voltage - Reverse Standoff (Typ) 7.5V Max
Reverse Standoff Voltage 7.5V
Forward Voltage 1.3V
Bidirectional Channels 12
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 7.5V
Capacitance @ Frequency 16pF @ 1MHz

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
