P6KE6V8A
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS Diodes - Transient Voltage Suppressors 600W 6.8V Unidirect
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1496
≥1 USD $0.1496
Inventory: 40471
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series P6KE, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Through Hole
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 4nF
Subcategory Transient Suppressors
Power Rating 600W
Voltage - Rated DC 6.8V
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Form WIRE
Base Part Number P6KE
Pin Count 2
Operating Supply Voltage 5.8V
Number of Elements 1
Polarity Unidirectional
Leakage Current 10mA
Element Configuration Single
Power Dissipation 5W
Case Connection ISOLATED
Power Line Protection No
Current - Peak Pulse (10/1000μs) 298A 8/20μs
Max Reverse Leakage Current 10mA
Clamping Voltage 13.4V
Peak Pulse Current 298A
Reverse Standoff Voltage 5.8V
Max Surge Current 57A
Peak Pulse Power 600W
Test Current 10mA
Breakdown Voltage 6.45V
Capacitance @ Frequency 4000pF @ 1MHz
Reverse Breakdown Voltage 6.45V
Max Breakdown Voltage 7.14V
Number of Unidirectional Channels 1
Dimensions
Diameter 3.53 mm
Height 3.53mm
Length 6.75mm
Width 3.53mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
