P6KE56ARL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
DO-204AC DO-15Axial P6KE TRANSIL? 1 Through Hole Zener Tvs Diode 53.2V 40A 8/20mus 600W 700pF @ 1MHz
PDF
/
Inventory: 1589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Capacitance-Min 700pF
Number of Unidirectional Channels 1
Reverse Current-Max 5μA
Reverse Breakdown Voltage 53.2V
Capacitance @ Frequency 700pF @ 1MHz
Breakdown Voltage 53.2V
Test Current 1mA
Peak Pulse Power 600W
Reverse Standoff Voltage 48V
Peak Pulse Current 40A
Clamping Voltage 100V
Voltage - Clamping (Max) @ Ipp 100V
Current - Peak Pulse (10/1000μs) 40A 8/20μs
Power Line Protection No
Case Connection ISOLATED
Leakage Current 500μA
Configuration SINGLE
Polarity Unidirectional
Number of Elements 1
Pin Count 2
Base Part Number P6KE
Terminal Form WIRE
Technology AVALANCHE
Max Power Dissipation 600W
Subcategory Transient Suppressors
Additional Feature UL RECOGNIZED
Applications General Purpose
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series P6KE, TRANSIL?
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-204AC, DO-15, Axial
Mounting Type Through Hole
Mount Through Hole
