P6KE440CA
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
P6KE Series 600 W 440 V Bi-Directional Axial TVS Diode - DO-204AC
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.49368
≥100 USD $0.343024
≥500 USD $0.267854
≥1000 USD $0.217712
≥3000 USD $0.194621
Inventory: 7012
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Weight 400.011771mg
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series P6KE, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Axial
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 350pF
Subcategory Transient Suppressors
Power Rating 600W
Voltage - Rated DC 440V
Max Power Dissipation 600W
Technology AVALANCHE
Terminal Form WIRE
Base Part Number P6KE
Pin Count 2
Operating Supply Voltage 376V
Number of Elements 1
Polarity Bidirectional
Number of Channels 1
Leakage Current 500μA
Element Configuration Single
Power Dissipation 5W
Case Connection ISOLATED
Power Line Protection No
Current - Peak Pulse (10/1000μs) 5.2A 8/20μs
Max Reverse Leakage Current 500μA
Clamping Voltage 776V
Peak Pulse Current 5.2A
Reverse Standoff Voltage 376V
Max Surge Current 5.2A
Peak Pulse Power 600W
Test Current 1mA
Breakdown Voltage 418V
Capacitance @ Frequency 175pF @ 1MHz
Reverse Breakdown Voltage 418V
Max Breakdown Voltage 462V
Dimensions
Diameter 3.56 mm
Height 3.53mm
Length 6.75mm
Width 3.53mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
