P6KE15CA
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 12.8VWM 27.2VC DO15
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.176
≥1 USD $0.176
Inventory: 2956
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series P6KE, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Applications General Purpose
Additional Feature UL RECOGNIZED
Subcategory Transient Suppressors
Voltage - Rated DC 15V
Technology AVALANCHE
Terminal Form WIRE
Base Part Number P6KE
Pin Count 2
Operating Supply Voltage 12.8V
Number of Elements 1
Leakage Current 500μA
Element Configuration Single
Power Dissipation 600W
Case Connection ISOLATED
Power Line Protection No
Current - Peak Pulse (10/1000μs) 147A 8/20μs
Max Reverse Leakage Current 500μA
Voltage - Clamping (Max) @ Ipp 27.2V
Clamping Voltage 27.2V
Voltage - Reverse Standoff (Typ) 12.8V
Peak Pulse Current 147A
Reverse Standoff Voltage 13V
Max Surge Current 147A
Peak Pulse Power 600W
Direction Bidirectional
Test Current 1mA
Breakdown Voltage 14.3V
Capacitance @ Frequency 950pF @ 1MHz
Reverse Breakdown Voltage 14.3V
Max Breakdown Voltage 15.8V
Diode Capacitance-Min 950pF
Dimensions
Diameter 3.6 mm
Length 7.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
