LNBTVS6-221S
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20V 32V SMC
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22135
≥1 USD $0.22135
≥10 USD $0.1824
≥100 USD $0.1767
≥500 USD $0.171
≥1000 USD $0.1653
Inventory: 24710
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series LNBTVS, TRANSIL?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Applications General Purpose
Additional Feature UL RECOGNIZED
Capacitance 6pF
Subcategory Transient Suppressors
Power Rating 3kW
Voltage - Rated DC 22V
Technology AVALANCHE
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Depth 6.25mm
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number LNBTVS
Pin Count 2
Operating Supply Voltage 20V
Number of Elements 1
Working Voltage 20V
Polarity Unidirectional
Leakage Current 200nA
Element Configuration Single
Power Dissipation 3kW
Power Line Protection No
Power - Peak Pulse 22500 22.5kW
Current - Peak Pulse (10/1000μs) 500A 8/20μs
Max Reverse Leakage Current 200nA
Clamping Voltage 32V
Peak Pulse Current 500A
Reverse Standoff Voltage 20V
Max Surge Current 500A
Peak Pulse Power 3kW
Test Current 1mA
Breakdown Voltage 22V
Reverse Breakdown Voltage 22V
Non-rep Peak Rev Power Dis-Max 3000W
Max Breakdown Voltage 24.2V
Number of Unidirectional Channels 1
