LNBTVS6-220S
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20V 35V SMC
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.53675
≥1 USD $0.53675
≥10 USD $0.4408
≥100 USD $0.42655
≥500 USD $0.41325
≥1000 USD $0.399
Inventory: 4015
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
REACH SVHC No SVHC
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.25mm
Technical
ESD Protection Yes
Max Breakdown Voltage 24.2V
Non-rep Peak Rev Power Dis-Max 3000W
Breakdown Voltage 22V
Unidirectional Channels 1
Test Current 1mA
Peak Pulse Power 3kW
Max Surge Current 500A
Reverse Standoff Voltage 20V
Peak Pulse Current 500A
Clamping Voltage 35V
Max Reverse Leakage Current 1μA
Current - Peak Pulse (10/1000μs) 500A 8/20μs
Power - Peak Pulse 22500 22.5kW
Power Line Protection No
Power Dissipation 5W
Element Configuration Single
Leakage Current 200nA
Polarity Unidirectional
Working Voltage 20V
Number of Elements 1
Operating Supply Voltage 20V
Pin Count 2
Base Part Number LNBTVS
Time@Peak Reflow Temperature-Max (s) 10
Depth 6.25mm
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 2kW
Voltage - Rated DC 22V
Power Rating 2kW
Subcategory Transient Suppressors
Capacitance 6pF
Additional Feature UL RECOGNIZED
Applications General Purpose
Terminal Finish Matte Tin (Sn) - annealed
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series LNBTVS, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
