LNBTVS4-221
RoHS
RoHS compliant
RoHS compliantPackage DO-201AA, DO-27, Axial
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20VWM 32VC DO201
PDF
/
Buying Options
Total Price: USD $7.15
Unit Price: USD $7.15065
≥1 USD $7.15065
≥10 USD $5.8672
≥100 USD $5.68385
≥500 USD $5.5005
≥1000 USD $5.31715
Inventory: 11409
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Surface Mount NO
Diode Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Box (TB)
Series LNBTVS
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Additional Feature UL RECOGNIZED
Subcategory Transient Suppressors
Technology AVALANCHE
Terminal Form WIRE
Pin Count 2
JESD-30 Code O-PALF-W2
Number of Elements 1
Polarity UNIDIRECTIONAL
Configuration SINGLE
Power Dissipation-Max 5W
Case Connection ISOLATED
Power Line Protection No
Voltage - Breakdown (Min) 22V
Power - Peak Pulse 2000W 2kW
Current - Peak Pulse (10/1000μs) 331A 8/20μs
Voltage - Clamping (Max) @ Ipp 32V
Voltage - Reverse Standoff (Typ) 20V
Unidirectional Channels 1
Breakdown Voltage 23.1V
Rep Pk Reverse Voltage-Max 20V
Non-rep Peak Rev Power Dis-Max 2000W
Clamping Voltage-Max 32V
Compliance
RoHS Status ROHS3 Compliant
