LDP01-30AY
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 27V 40V D2PAK
PDF
/
Buying Options
Total Price: USD $2.49
Unit Price: USD $2.4904
≥1 USD $2.4904
≥10 USD $2.09
≥100 USD $1.690744
≥500 USD $1.502846
Inventory: 2809
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Breakdown Voltage 28.9V
Unidirectional Channels 1
Reverse Standoff Voltage 27V
Peak Pulse Current 125A
Voltage - Reverse Standoff (Typ) 27V
Clamping Voltage 40V
Voltage - Clamping (Max) @ Ipp 40V
Power Line Protection No
Case Connection CATHODE
Configuration SINGLE
Polarity UNIDIRECTIONAL
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number LDP01
Terminal Form GULL WING
Terminal Position SINGLE
Technology AVALANCHE
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q101, LDP01Y, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -55°C~175°C TJ
Physical
Diode Element Material SILICON
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 9 Weeks
