ITA25B1
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24VWM 38VC 8SOIC
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5529
≥1 USD $0.5529
≥10 USD $0.4541
≥100 USD $0.43985
≥500 USD $0.4256
≥1000 USD $0.41135
Inventory: 1741
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 4mm
Length 5mm
Height 1.75mm
Technical
ESD Protection Yes
Max Breakdown Voltage 25V
Reverse Breakdown Voltage 25V
Capacitance @ Frequency 300pF @ 1MHz
Bidirectional Channels 5
Breakdown Voltage 25V
Test Current 1mA
Peak Pulse Power 300W
Max Surge Current 40A
Reverse Standoff Voltage 24V
Peak Pulse Current 25A
Clamping Voltage 38V
Max Reverse Leakage Current 4μA
Current - Peak Pulse (10/1000μs) 25A 8/20μs
Power Line Protection No
Element Configuration Common Cathode
Leakage Current 4μA
Number of Channels 4
Polarity Bidirectional
Working Voltage 24V
Number of Elements 6
Operating Supply Voltage 24V
Pin Count 8
Base Part Number ITA25
Time@Peak Reflow Temperature-Max (s) 30
Depth 4mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 300W
Voltage - Rated DC 25V
Power Rating 300W
Subcategory Transient Suppressors
Capacitance 300pF
Applications General Purpose
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series ITA, TRANSIL?
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
