ESDZV5-1BV2
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE ST0201
PDF
/
Buying Options
Total Price: USD $0.17
Unit Price: USD $0.1672
≥1 USD $0.1672
≥10 USD $0.12056
≥100 USD $0.065032
≥500 USD $0.05111
≥1000 USD $0.03549
≥3000 USD $0.029401
Inventory: 54880
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Non-rep Peak Rev Power Dis-Max 45W
Rep Pk Reverse Voltage-Max 5.5V
Diode Type TRANS VOLTAGE SUPPRESSOR DIODE
Configuration SINGLE
Polarity BIDIRECTIONAL
Number of Elements 1
Operating Temperature (Min) -40°C
Operating Temperature (Max) 150°C
JESD-30 Code R-PBCC-N2
Reference Standard IEC-61000-4-2, 4-4, 4-5
Base Part Number ESDZV5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position BOTTOM
Technology AVALANCHE
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 15 Weeks
