ESDCAN24-2BLY
RoHS
RoHS compliant
RoHS compliantPackage TO-236-3, SC-59, SOT-23-3
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24V 40V SOT23-3
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.25872
≥100 USD $0.13068
≥500 USD $0.115808
≥1000 USD $0.090121
Inventory: 128078
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Number of Pins 3
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q101
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications Automotive, CAN
HTS Code 8541.10.00.50
Capacitance 30pF
Subcategory Transient Suppressors
Max Power Dissipation 230W
Peak Reflow Temperature (Cel) 260
Depth 1.3mm
Base Part Number ESDCAN24
Working Voltage 24V
Number of Channels 2
Leakage Current 100nA
Element Configuration Dual
Power Line Protection No
Voltage - Breakdown (Min) 26.2V
Current - Peak Pulse (10/1000μs) 5.5A 8/20μs
Max Reverse Leakage Current 100nA
Voltage - Clamping (Max) @ Ipp 40V
Clamping Voltage 43V
Voltage - Reverse Standoff (Typ) 24V Max
Peak Pulse Current 5.5A
Reverse Standoff Voltage 24V
Peak Pulse Power 230W
Direction Bidirectional
Breakdown Voltage 27V
Capacitance @ Frequency 30pF @ 1MHz
ESD Protection Yes
Max Junction Temperature (Tj) 150°C
Dimensions
Height 1.5mm
Length 2.9mm
Width 1.75mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
