ESDAVLC8-1BT2

STMicroelectronics
RoHS
RoHS RoHS compliant
Package SOD-882
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 3VWM SOD882T
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.27016
≥100 USD $0.136136
≥500 USD $0.120613
≥1000 USD $0.093861
≥3000 USD $0.084005
Inventory: 1602
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOD-882
Number of Pins 2
Diode Element Material SILICON

Technical

Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series ESDA, TRANSIL?
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications General Purpose
Capacitance 5.5pF
Subcategory Transient Suppressors
Max Power Dissipation 30W
Technology AVALANCHE
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Depth 600μm
Base Part Number ESDAVLC8
Pin Count 2
Number of Elements 1
Number of Channels 1
Leakage Current 50nA
Element Configuration Single
Power Line Protection No
Max Reverse Leakage Current 50nA
Peak Pulse Current 1.3A
Reverse Standoff Voltage 3V
Max Surge Current 1.3A
Peak Pulse Power 30W
Direction Bidirectional
Breakdown Voltage 8.5V
Capacitance @ Frequency 4.5pF @ 1MHz
Max Breakdown Voltage 11V
ESD Protection Yes

Dimensions

Height 350μm
Length 1mm
Width 650μm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
