ESDAULC6-3BP6
RoHS
RoHS compliant
RoHS compliantPackage SOT-563, SOT-666
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5VWM SOT666
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.33176
≥100 USD $0.199144
≥500 USD $0.18436
≥1000 USD $0.125365
Inventory: 85834
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 1.7mm
Length 1.7mm
Height 600μm
Technical
ESD Protection Yes
Max Breakdown Voltage 9.2V
Breakdown Voltage 6V
Direction Bidirectional
Reverse Standoff Voltage 5V
Peak Pulse Current 6A
Max Reverse Leakage Current 500nA
Power Line Protection No
Leakage Current 500nA
Number of Channels 3
Working Voltage 5V
Number of Elements 4
Pin Count 6
Base Part Number ESDAULC6
Time@Peak Reflow Temperature-Max (s) 30
Depth 1.3mm
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position DUAL
Technology AVALANCHE
Subcategory Transient Suppressors
Capacitance 1.25pF
HTS Code 8541.10.00.50
Additional Feature HIGH RELIABILITY, ULTRA LOW CAPACITANCE
Applications General Purpose
Min Operating Temperature -55°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series ESDA
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case SOT-563, SOT-666
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
