ESDALCL5-1BM2
RoHS
RoHS compliant
RoHS compliantPackage SOD-882
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 3V SOD882
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4048
≥1 USD $0.4048
≥10 USD $0.28248
≥100 USD $0.14256
≥500 USD $0.116266
≥1000 USD $0.086266
≥3000 USD $0.072582
Inventory: 1253
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 650μm
Length 1mm
Height 450μm
Technical
ESD Protection Yes
Capacitance @ Frequency 26pF @ 1MHz
Bidirectional Channels 1
Breakdown Voltage 13V
Test Current 1mA
Direction Bidirectional
Peak Pulse Power 150W
Max Surge Current 9A
Reverse Standoff Voltage 3V
Peak Pulse Current 9A
Voltage - Reverse Standoff (Typ) 3V
Max Reverse Leakage Current 10nA
Power Line Protection No
Element Configuration Single
Leakage Current 10nA
Operating Supply Voltage 5V
Base Part Number ESDALCL5
Depth 600μm
Subcategory Transient Suppressors
Capacitance 30pF
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ESDA
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 2
Package / Case SOD-882
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 11 Weeks
