ESDALC20-1BF4
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 20V 37V 0201
PDF
/
Buying Options
Total Price: USD $0.23
Unit Price: USD $0.2288
≥1 USD $0.2288
≥10 USD $0.15752
≥100 USD $0.076824
≥500 USD $0.064046
≥1000 USD $0.044502
≥3000 USD $0.03857
Inventory: 273874
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Capacitance @ Frequency 10.5pF @ 1MHz
Bidirectional Channels 1
Direction Bidirectional
Peak Pulse Power 90W
Reverse Standoff Voltage 20V
Peak Pulse Current 2.4A
Clamping Voltage 37V
Current - Peak Pulse (10/1000μs) 2.4A 8/20μs
Voltage - Breakdown (Min) 22V
Power Line Protection No
Element Configuration Single
Working Voltage 20V
Case Code (Imperial) 0201
Case Code (Metric) 0603
Base Part Number ESDALC20
Applications General Purpose
Type Zener
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ESDA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 2
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 15 Weeks
