ESDA7P60-1U1M

STMicroelectronics
RoHS
RoHS RoHS compliant
Package 0603 (1610 Metric)
Category Circuit Protection / TVS - Diodes
Description TVS DIODE 5V 11.6V 1610
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.24376
≥100 USD $0.14608
≥500 USD $0.135274
≥1000 USD $0.091986
≥3000 USD $0.084682
Inventory: 69064
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Technical

Max Breakdown Voltage 7.2V
Breakdown Voltage 6.4V
Unidirectional Channels 1
Peak Pulse Power 700W
Reverse Standoff Voltage 5V
Peak Pulse Current 60A
Clamping Voltage 11.6V
Voltage - Clamping (Max) @ Ipp 11.6V
Current - Peak Pulse (10/1000μs) 60A 8/20μs
Power Line Protection No
Polarity Unidirectional
Base Part Number ESDA7
Applications General Purpose
Type Zener
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ESDA
Packaging Cut Tape (CT)
Operating Temperature -55°C~150°C TJ

Physical

Number of Pins 2
Package / Case 0603 (1610 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 11 Weeks
