ESDA6V1SC6Y
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 5.2V 19V SOT23-6
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.30976
≥100 USD $0.2156
≥500 USD $0.168344
≥1000 USD $0.136822
Inventory: 15460
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 3mm
Technical
Breakdown Voltage 6.1V
Unidirectional Channels 4
Direction Unidirectional
Peak Pulse Power 400W
Reverse Standoff Voltage 5.2V
Peak Pulse Current 18A
Clamping Voltage 22V
Voltage - Clamping (Max) @ Ipp 19V
Current - Peak Pulse (10/1000μs) 18A 8/20μs
Power Line Protection No
Leakage Current 20μA
Working Voltage 5.2V
Number of Elements 4
Base Part Number ESDA6
Depth 1.75mm
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Max Power Dissipation 400W
Capacitance 190pF
Applications Automotive
Type Zener
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, ESDAY, TRANSIL?
Packaging Cut Tape (CT)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 13 Weeks
