ESDA6V1-5SC6Y
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Circuit Protection / TVS - Diodes
Description
ESDA Series 6.1 V 50 pF Automotive 5-Line ESD Protection TVS Diode - SOT-23-6
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3344
≥1 USD $0.3344
≥10 USD $0.26136
≥100 USD $0.156904
≥500 USD $0.145323
≥1000 USD $0.098815
Inventory: 62130
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Non-rep Peak Rev Power Dis-Max 80W
Unidirectional Channels 5
Voltage - Reverse Standoff (Typ) 5.2V
Voltage - Clamping (Max) @ Ipp 11.4V
Current - Peak Pulse (10/1000μs) 7A 8/20μs
Power - Peak Pulse 80W
Voltage - Breakdown (Min) 6.1V
Power Line Protection No
Polarity UNIDIRECTIONAL
Number of Elements 5
JESD-30 Code R-PDSO-G6
Reference Standard AEC-Q101; IEC-61000-4-2
Base Part Number ESDA6
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Applications Automotive
Type Zener
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, ESDA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SOT-23-6
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 13 Weeks
