ESDA25W5 image
Favorite
ESDA25W5 image
Favorite
RoHS
RoHS RoHS compliant
Package 5-TSSOP, SC-70-5, SOT-353
Category Circuit Protection / TVS - Diodes
Description STMICROELECTRONICS ESDA25W5ESD Protection Device, TVS, SOT-323, 5 Pins, 1.2 V
PDF
/
Buying Options
Total Price: USD $0.41
Unit Price: USD $0.4136
≥1 USD $0.4136
≥10 USD $0.32208
≥100 USD $0.193336
≥500 USD $0.179045
≥1000 USD $0.121757
Inventory: 1616
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Width 1.35mm
Length 2.2mm
Height 1mm

Technical

ESD Protection Yes
Max Breakdown Voltage 30V
Reverse Breakdown Voltage 25V
Breakdown Voltage 30V
Test Current 1mA
Direction Unidirectional
Peak Pulse Power 150W
Reverse Standoff Voltage 24V
Peak Pulse Current 15A
Max Reverse Leakage Current 1μA
Power Line Protection No
Element Configuration Common Anode
Leakage Current 1μA
Working Voltage 24V
Number of Elements 4
Operating Supply Voltage 1.2V
Pin Count 5
Base Part Number ESDA25
Depth 1.35mm
Terminal Form GULL WING
Terminal Position DUAL
Technology AVALANCHE
Voltage - Rated DC 25V
Power Rating 400W
Subcategory Transient Suppressors
Capacitance 30pF
Applications General Purpose
Type Zener
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ESDA, TRANSIL?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Diode Element Material SILICON
Weight 4.535924g
Number of Pins 5
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 13 Weeks
