ESDA25SC6
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Circuit Protection / TVS - Diodes
Description
TVS DIODE 24VWM SOT23-6
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.46024
≥100 USD $0.31988
≥500 USD $0.249726
≥1000 USD $0.202981
Inventory: 131708
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Number of Pins 6
Diode Element Material SILICON
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series ESDA, TRANSIL?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Termination SMD/SMT
ECCN Code EAR99
Type Zener
Terminal Finish Matte Tin (Sn) - annealed
Applications General Purpose
Capacitance 60pF
Subcategory Transient Suppressors
Power Rating 300W
Voltage - Rated DC 25V
Max Power Dissipation 300W
Technology AVALANCHE
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Depth 1.75mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ESDA25
Pin Count 6
Operating Supply Voltage 5.3V
Number of Elements 4
Working Voltage 25V
Leakage Current 1μA
Element Configuration Common Anode
Power Line Protection No
Max Reverse Leakage Current 1μA
Clamping Voltage 30V
Reverse Standoff Voltage 24V
Peak Pulse Power 300W
Direction Unidirectional
Test Current 1mA
Breakdown Voltage 25V
Reverse Breakdown Voltage 25V
ESD Protection Yes
Dimensions
Height 1.3mm
Length 3.05mm
Width 1.75mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
